36
Rev. 1.0 31/01/2020
• Composition of setup menu for the Data Logger menu
P8.1 Datalogging
Access this menu to select the data acquisition mode:
• MANUAL: The data is acquired only when the user presses the button .
• HOURS - MINUTES: Set an automatic data acquisition frequency range.
Use the directional keys to move from MANUAL to HOURS or MINUTES. Access with and, as
indicated by the icon , change the value of the acquisition time. Confirm the setting with the key
.
• Use of automatic Data Logger
In measure mode press to start and end automatic recording.
When the automatic data saving is running, the icon flashes on the display.
When it is set, but not in operation, the icon on the screen remains fixed. When the 1000 total values
are reached, the recording stops automatically.
Note: Scrolling through the parameters, the recording stops.
P8.2 Memory emptying
Access this menu and select YES to clear the saved data and empty the memory.
Next to the M+ icon. It shows the total number of data stored.
P8.3 Saving destination
Access this menu to select the destination for saving the recorded values:
• MEMORY: -default setting- The recorded data is saved in the internal memory of the device. This series
of instruments can store up to 1000 data in total, the progressive registration number appears next to
the M+ icon.
IMPORTANT: If you are working with the DataLink + software active, the data is automatically saved on the
PC and NOT on the instrument's memory
• PRINTER: The data are printed directly on an external printer connected via the RS232 port (see outputs
connections). Access menu P8.4 to select which information to print in the header.
P8.4 Print format
