10 Problem Solving
Problem Possible Solutions
Power light flashing Ensure supply to BATTERY connector within limits.
No lights on display. Fan not running Ensure supply to BATTERY connector within specified limits.
Ensure supply leads correctly orientated.
Ensure that BAT FUSE correctly seated in socket and fuse not
blown.
General Fault Light & Flashing Power
Light only displayed. Fan not running.
Ensure that supply voltage is within specified limits (please
refer to Table 11-1)
No lights on display. Fan running OK. Ensure ribbon cable fully seated into main & display boards.
Flow HI/LO light on Ensure sampling pipes correctly installed, lid fitted and box
fully sealed.
Ensure flow calibration procedure has been carried out (please
refer to Section 6.2).
Ensure that filters are clean (Chapter 8).
Flow reading on Bargraph display moves
erratically.
Decrease Flow sensitivity setting and re-calibrate air flows
(Section 6.2).
Flow reading unresponsive to broken or
blocked pipes
Increase Flow sensitivity setting and re-calibrate air flows
(Section 6.2).
Wrong Detector responds to smoke Ensure that detectors are fitted in correct position i.e. Address
1 in Detector or Channel position 1, Address 2 in Detector or
Channel position 2 (Chapter 5).
Smoke Detector Fault indicated Ensure that correct address has been set (Chapter 5).
Ensure detector fully seated into base.
Ensure detector optics are clean (Chapter 8).
Detector(s) unresponsive to smoke
tests
Ensure supplied baffles are correctly fitted.
Ensure that sampling pipe installed correctly and is
undamaged (Chapter 4).
Ensure unit cover correctly fitted.
Ensure that holes and pipe length do not exceed limits and the
fan speed is sufficient (Section Figure 4-5).
Ensure that recommended test method is used (Chapter 7).
