R90 ONLINE USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS)
Xtreme Power Conversion Corporation (Rev 3/7/14) Page 50
Bypass voltage lower limit setting
BYPASS VOLTAGE LOWER LIMIT SETTING
(Note: the information in the red box will be flashing)
When in bypass voltage upper limit setting press On or when in parallel ID setting press Off to go
to the bypass voltage lower limit setting mode. The bypass voltage lower limit line flashes as in the
above image. Use the Enter button to choose different bypass voltage lower limit. Bypass voltage
lower limit range is 20%, 30%, 45%. Press Off or On to exit the bypass voltage lower limit setting
(save the bypass voltage lower limit setting), and then goes to bypass voltage upper limit setting or
parallel ID setting.
