R90 ONLINE USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS)
Xtreme Power Conversion Corporation (Rev 3/7/14) Page 55
18
Soft Start failed
Continuously
Fault LED on
19
Rectifier Over Temperature
Twice per second
Fault LED on
20
Inverter Over Temperature
Twice per second
Fault LED on
21
Input Neutral Line missing
Twice per second
Fault LED on
22
Battery Reverse
Twice per second
Fault LED on
23
Cable Connection error
Twice per second
Fault LED on
24
CAN Communication fault
Twice per second
Fault LED on
25
Parallel Load Sharing fault
Twice per second
Fault LED on
26
Battery Over Voltage
Once per second
Fault LED blinking
27
Mains Site Wiring fault
Once per second
Fault LED blinking
28
Bypass Site Wiring fault
Once per second
Fault LED blinking
29
Output Short-Circuit
Once per second
Fault LED blinking
30
Rectifier Over Current
Once per second
Fault LED blinking
31
Bypass Over Current
Once per second
BPS LED blinking
32
Overload
Once per second
INV or BPS LED
blinking
33
No Battery
Once per second
Battery LED blinking
34
Battery Under Voltage
Once per second
Battery LED blinking
35
Battery Low Pre-warning
Once per second
Battery LED blinking
36
Internal Communication Error
Once per 2 seconds
Fault LED blinking
EVENT LOG
UPS ALARM WARNING
BUZZER
LED
37
DC component over limit
Once per 2 seconds
INV LED blinking
38
Parallel Overload
Once per 2 seconds
INV LED blinking
39
Mains Volt. Abnormal
Once per 2 seconds
Battery LED on
40
Mains Freq. Abnormal
Once per 2 seconds
Battery LED on
41
Bypass Not Available
BPS LED blinking
42
Bypass unable to trace
BPS LED blinking
43
Inverter on invalid
Options
CAUTION!
For network management configuration and use, refer to the separate user manual -
Network Management Card with Environmental Monitor, which is shipped with the
SNMP card.
SNMP Card: external SNMP optional
• Connect the external SNMP adapter to the SNMP port indicated
• Tighten the screws
