Xtreme 20kVA - Technical Specifications and Warranty; Technical Specifications

R90 ONLINE USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS)
Xtreme Power Conversion Corporation (Rev 3/7/14) Page 59
SPECIFICATIONS
Model
R90-20KVA
Capacity
20kVA / 18Kw
Input
Phase
3 Phase / 4 Wires + Ground
Rated Voltage
380/220VAC, 400/230VAC, 415/240VAC
Voltage Range
208 - 478 VAC
Frequency Range
40 - 70 Hz
Power Factor
≥ 0.99
Bypass Voltage Range
Max: +15% (optional +5%, +10%, +25%); Min: -45%
(optional -20%, -30%); Frequency range: ± 10%
Current Harmonic
≤ 3% (100% non-linear load)
Output
Phase
3 Phase / 4 Wires + Ground
Rated Voltage
380/220VAC, 400/230VAC, 415/240VAC
Power Factor
0.9
Voltage Precision
± 2%
Frequency
Utility Mode: ± 1%, ± 2%, ± 4%, ± 5%, ± 10% of the
rated frequency (optional)
Battery Mode: 50 / 60 Hz ± 0.2
Crest Factor
3:1
Transfer Time
Utility to Battery: 0ms; Utility to Bypass: 0ms
Overload Capacity
≤ 110% = 60 min; ≤ 125% = 10 min; ≤ 150% = 1 min
≥ 150% = immediate shutdown
Total Harmonic Distortion
≤ 2% with linear load; ≤ 5% with non-linear load
Efficiency
ECO Mode ≥ 98%; Normal Mode ≥ 95.5%
Battery
Voltage
± 192 VDC (programmable to ± 204/216/228/240 VAC)
Charge Current
1A (programmable to 6A)
Backup Time
over 290 minutes with (8) R90-EBP32 (optional)
Physical
UPS dimensions
(W x D x H)
17.4 x 22.8 x 5.2 in (443 x 580 x 131 mm)
UPS Weight
68.4 lbs (31 kg)
EBP32 dimensions
(W x D x H)
17.25 x 27.5 x 5.25 in (438 x 698 x 133 mm)
EBP32 Weight
205 lbs (93 kg)
Options
Input / Output cord kits, rack mount hardware,
Maintenance bypass, Output distribution, SNMP
Environment
Operating Temperature
32 - 104°F (0-40°C)
Humidity
0 – 95% non-condensing
Altitude
11,500 ft (3500 m) above sea level
Approvals
CE, EN/IEC 62040-2, EN/IEC 62040-1-1
