12
3.4. Vertical installation – increased barrier effect
- To increase the barrier effect, the curtain can be installed on both sides of the curtained opening (e.g.
permanently open gates for loading and unloading trains)
- The curtains shall be installed in accordance with the same procedure as described in points 3.2 and 3.3.
3.5. Horizontal installation
- The surface (e.g. wall, brickwork) and auxiliary structures necessary to anchor the curtain must have an
adequate load capacity based on the weight of the selected curtain type. Neither the anchoring material
nor the auxiliary structures are provided by the supplier. The owner provides for himself/herself according
to local conditions. See paragraph 3.5.2 for examples of installation.
- For the correct functionality of the curtain (curtaining the opening), the curtain must overlap on each side
by at least 100 mm beyond the width of the curtained opening. If the width of the opening is greater than or
equal to the length of the curtain, you should attach an additional curtain, see Point 3.6.
3.5.1. Preparation for the curtain suspension
- Unpack the curtain from the top of the curtain only (the curtain is delivered in the horizontal position), and
proceed as follows:
o remove wooden battens,
o remove plastic packaging and tapes.
ACCORDING TO THE WIDTH OF THE DOOR OPENING,
DEPENDING ON THE ACTIVE BLOWING DISTANCE (AVAILABLE IN THE TECHNICAL
IN CASE OF OPENING WIDTH MORE THAN 8 M, WE RECOMMEND
INSTALLING THE CURTAINS ON BOTH SIDES OF THE DOOR OPENING
THE MAXIMUM HEIGHT OF THE CHAINED
CURTAINING, IT IS NECESSARY TO
OBSERVE OVERLAPPING OF THE
WIND CURTAIN BY ABOUT 50-
