14
- Installation on the wall using the wall
console and threaded rods M8-10. Consoles
and M8-10 threaded rods are not included in
the delivery. It is ensured by the user
according to local conditions.
3.5.4.1. Examples of Curtain Suspension – Horizontal Installation
3.5.5. Measurement of anchoring holes
- Measure the anchoring holes according to the selected curtain type and anchoring type (according to the
suspension layout) - see the main dimensions 2.2 - dimension D.
3.5.6. Installation of the auxiliary anchoring structure
- Install auxiliary anchoring structures, e.g.: wall consoles. Select suitable anchoring material and tools
according to the material and the type of the background. Anchoring material is not part of the delivery.
3.5.7. Installation – hanging the curtain into the working position
- Lift the partially unpacked curtain according to section 3.5.1. with the installation hinges, using a suitable
handling technique (e.g. a lift truck) to the prepared assembly point. Partial packaging (pallet, protective
polystyrene) is used to protect the product from damage by scratching.
THREADED RODS
THREADED RODS
AUXILIARY CONSOLE
- Installation on the ceiling using the M8-10
threaded rods. Threaded rods M8-10 are
not included in the delivery. It is ensured
by the user according to local conditions.
