16
- To facilitate suspension, we recommend using simple hinges (WIND-HINGE accessories), which are
attached to the prepared threaded nuts on the side of the curtain (use M6x20 screws). Use it also in case of
mounting via "WIND-CONNECT" connecting piece
- Install the "WIND-CONNECT" connecting piece onto the side of the first
chained curtain, so that 1/2 of the connecting piece protrudes from the
chained curtain. Use 6 screws M6x20 (part of the connecting part
packing) to install the connection piece.
- Chained curtains must not be connected before lifting them to the
working position. Always handle only one curtain at a time, intended
for chaining. The curtains will be connected only after anchoring it to
the wall or the ceiling.
ASSEMBLY ILLUSTRATION - CHAINING OF CURTAINS + DISTANCE CONDITIONS
ING, IT IS NECESSARY TO OBSERVE
OVERLAPPING OF THE WIND CURTAIN BY ABOUT 50-100mm
THE MAXIMUM HEIGHT DOOR OPENING IS 8m
