40 SUBMENU
DIAGNOSTICS
In this parameters the current temperature, voltage and frequency of the chosen
HYDROVAR can be monitored even during operation of the unit.
These parameters are only to read!
Possible settings: 1-8
43
43 TEMP. INVERTER
XX % XX°C
Temperature of the selected unit
The current value determines the temperature inside the selected HYDROVAR and is shown
in °C and also in percent of the max. allowed temperature.
This value determines the output current of the HYDROVAR in percent to the max. rated
current output.
This value determines the input voltage connected to the HYDROVAR.
This value determines the output frequency generated from the HYDROVAR
This parameter gives information about the software version of the BASIC drive (located on
the main board).
Possible indications:
00 All power sizes (HV2.015-4.110) prior production 05/2008
01 Power sizes HV2.015-4.040 - related to control board software V01.3 and above
02 Power sizes HV4.055-4.220 - related to control board software V01.3 and above
41
41 PROD. DATE
XX.XX.XXXX
production date of the HYDROVAR (MASTER /SINGLE
only)
42
42 SEL. INVERTER
* 1 *
Selection of the desired unit
44
44 CURR. INVERTER
XXX %
Current of the selected unit
45
45 VOLT. INVERTER
XXX V
Voltage of the selected unit
46
46 OUTPUT FREQ.
XX.X Hz
Output frequency of the selected unit
47
47 VER.INVERTER
01
Specification version of the selected device
