SonTek, a Xylem brand
RiverSurveyor S5/M9 System Manual (February 2013)
65
Figure 76 shows the Find File screen that displays a menu for finding the firmware upgrade file.
If a file is not selected, an error message is displayed. You can navigate with the up/down keys
and select with the enter key. Additional options are available via the
MENU option. Select Open
to upload the firmware file.
Figure 76. Utilities – Firmware Upgrade Find File Screen
Application Settings (Figure 77): Activating the check-box for Bluetooth: Connect Automatical-
ly enables the software to connect to the first system detected. This menu is also used to apply
either Metric or English units. Typically, these options are applied as default settings. Select
DONE to update these settings and return to the Utilities Menu. In the bottom right of the win-
dow, the version of the software is indicated.
Figure 77. Utilities - Application Settings
