Multi 3630/3620 IDS Operation
ba77045d02 03/2020 9
4Operation
The meter can either be operated with IDS sensors or OxiTop
®
-IDS measuring
heads. Operation with OxiTop
®
-IDS measuring heads is possible only wireless.
Using <M_> switch between operating with IDS sensors and operating with
OxiTop
®
-IDS measuring heads.
On delivery, operation with IDS sensors is preset.
Prerequisites Prerequisites for operation with OxiTop
®
-IDS measuring heads:
 Meter Multi 3630 IDS or Multi 3620 IDS
with current firmware version
 Adapter WLM-M is connected to the meter Multi 3630/3620 IDS,
with current firmware version
 OxiTop
®
-IDS (/B) measuring heads
 Undisturbed radio link between OxiTop
®
-IDS measuring head and meter
 The radio connection is active at the OxiTop
®
-IDS measuring head
 No IDS sensor is connected to the meter
Communication
between OxiTop
®
-
IDS measuring head
and meter
Communication between the meter and OxiTop
®
-IDS measuring head only
starts after an OxiTop
®
-IDS measuring head was assigned to a sample.
This communication is used for the following purposes:
 Exchanging data and settings between meter and OxiTop
®
-IDS measuring
head
 Identifying OxiTop
®
-IDS measuring heads using the meter
(the LED at the measuring head indicates the communication)
Status LED
at the OxiTop
®
-IDS
measuring head
The status LED at the OxiTop
®
-IDS measuring head indicates the current state
of a measurement. The LED flashes slowly (approx. every 5 seconds).
The basic information and general operating principles are given in
the operating manual of your meter, e.g. operation, navigation in
the menu, setting the date, time and language.
The current firmware versions for the meters are available on the
Internet at www.wtw.com
(to carry out the firmware update: see
chapter 8 F
IRMWARE UPDATE) is displayed.
Color Explanation
Magenta Measurement is running.The measuring head can be
reached via radio.
Blue Measurement is running.
The measuring head OxiTop
®
-IDS cannot be reached via
radio.
