XYZ Machine Tools
ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Service & Parts List Manual
Electrical Box Parts List
Item
P/N
DESCRIPTION
Qty
1
24039
SHEETMETAL-SLX-DRIVE MODULE
0
2
24042
MODULE-SPINDLE CONTROL
1
3
24999-2
CABINET ASSY-PT4 -SL-CABLE BREAKOUT BOX-AUXILARY FUNCTIONS
1
4
22287-euro
AC DRIVE PROGRAMMED
1
5
20201
SERVO DRIVER ASSY
1
6
22283-2-3-30
WIREWAY- TYPE G LIGHT GRAY
1
7
22283-1-3-30
WIREWAY- TYPE G LIGHT GRAY
1
12
1/4-20X3/8 31Z
SCREW-PH-PHIL-EXT SEMS-STL-ZINC
7
13
10-32X3/8 31Z
SCREW-PH-PHIL-EXT SEMS-STL-ZINC
12
14
6-32X5/8 31B
SCREW-PH-PHIL-EXT SEMS-STL-BO
8
15
20327-3
SERVO DRIVER ASSY - 4050D
1
16
20689
CABLE ASSY-L2 SERVO DRIVERS TO CONN PCB
1
17
24181
CABLE ASSY-LATHE CBB TO SPINDLE CONTROL
1
21
22392-1-30
COVER- WIREWAY- TYPE G
1
22
22392-2-30
COVER- WIREWAY- TYPE G
1
23
22778
LABEL-REVISION LEVEL
1
24
22779-21
LABEL-
1
25
21786-4
ADAPTER ASSY - SLX E-STOP JUMPER
1
30
24360-SLX 1630
AC DRIVE PROGRAMMED - SLX 1630
1
31
24144
SHEETMETAL-SLX-POWER MODULE
1
32
21891
FILTER- HIGH POWER
1
33
21258-2
TRANSFORMER - 1.2kVA
1
34
21753-2
GROUND BAR-SLX 1630
1
35
22283-3/4-2-12
WIREWAY- TYPE G LIGHT GRAY
2
36
22392-3/4-12
COVER- WIREWAY- TYPE G
2
37
23037
DIODE-BRIDGE RECTIFIER-HIGH CURRENT-25 WATT
1
38
24426-1
RAIL-DIN
1
39
22557-1
TERMINAL BLOCK - 6mm BLOCK
5
40
23036
FUSE HOLDER-32 AMP-690V
6
41
22892-3
CONTACTOR -
1
42
22891
RELAY-DUAL CHANNEL
1
43
23152-2
FUSE-500 VOLT-
1
44
23152-25
FUSE-500 VOLT-
3
45
23152-4
FUSE-500 VOLT-
2
46
M6-1.0X6 10Z
SCREW-PH-PHIL-STL-ZINC
18
47
M5-0.8X16 10Z
SCREW-PH-PHIL-STL-ZINC
3
48
M5-0.8X6 10Z
SCREW-PH-PHIL-STL-ZINC
9
49
24299
TERMINAL BLOCK
1
50
21455-2
CABLE ASSY - SX AUX SAFETY I/O
1
51
24429
CABLE ASSY - 1630 SLX POWER CABLE
1
52
24424
TERMINAL BLOCK - JUMPER
1
53
24423
SUPPRESSOR - NOISE
1
54
M6 70Z
WASHER-FLAT USS-STL-ZINC
8
55
M6 73B
WASHER-SPLIT LOCK-STL-BO
8
