5. lnstallation
5.1. Install the TV Dongle
How to remove or install the Dongl
1. Use a screwdriver to remove the
screws from the cover of the Dongle
compartment. (Screw size:ST2.3×6mm)
3.Insert the TV Dongle into the HDMI
port inside the compartment. (Make
sure the Dongle is inserted firmly for
identification.)
2.Make sure that the TV Dongle's ports
have not been broken (as shown in the
following figure).
4. Connect the Micro USB cable to TV
Dongle and close the lid.
Lid
Tray
TV Dongle
Slot
Micro USB port
(Mark on the Back)
Micro HDMI port
(Mark on the Back)
Mounted TV Dongle
USB Power Cable
