Yaesu FT-60R/E - CD 1 xxx; CF 1 xxx; D 1 xxx

39
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
FT-60R/E Technical Supplement
C 1375 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- B a1
C 1376 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B c2
C 1377 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 1378 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1
C 1379 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- B a2
C 1380 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a2
C 1381 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1382 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 1383 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B a2
C 1384 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1385 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E3
C 1385 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 57- A E3
C 1386 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E2
C 1386 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 57- A E2
C 1387 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E2
C 1387 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 57- A E2
C 1388 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- B d1
C 1390 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d4
C 1391 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B g2
C 1392 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B d4
C 1393 CHIP CAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B d4
C 1394 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B b1
C 1395 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1397 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C2
C 1398 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A G2
C 1398 CERAMIC CAP. 100pF 50V B UP050B101K-A-B K28179004 3- A G2
C 1398 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 6- A G2
C 1400 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1403 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D2
C 1404 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1407 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1
C 1409 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B b3
C 1411 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- A G1
C 1412 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A E1
C 1412 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 3- A E1
C 1413 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BZ01D K22178294 1- B b2
C 1413 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 132- B b2
C 1414 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- B a4
C 1414 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 6- B a4
C 1415 CHIP TA.CAP. 10uF 6.3V TEESVP0J106M8R K78080055 2-3 A C1
C 1415 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 10- A C1
C 1416 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 4- B f2
C 1416 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 57- B f2
C 1417 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 4- B f3
C 1418 CERAMIC CAP. 0.001uF 50V B UP050B102K-A-B K28179001 W/ CE LABEL 4-129
C 1419 CHIP CAP. 0.22uF 10V B GRM188B11A224KA01D K22104801 5-9
CD1001 CERAMIC DISC JTBC450C7 H7901500 1- B g1
CD1001 CERAMIC DISC JTBM450CX7 H7901520 130- B g1
CF1001 CERAMIC FILTER LTWC450F H3900563 1- B g2
D 1001 DIODE DA221 TL G2070178 1- A E3
D 1002 DIODE 1SS400 TE61 G2070634 1- B c3
D 1003 DIODE UDZS TE-17 9.1B G2070868 1- A D3
D 1004 DIODE 1SS400 TE61 G2070634 1- A D3
D 1005 DIODE 1SS400 TE61 G2070634 1- A E3
D 1006 DIODE UDZS TE-17 5.1B G2070908 1- A D1
D 1006 DIODE EDZ TE-61 5.1B G2070998 10- A D1
D 1007 DIODE DAN222 TL G2070174 1- B f2
D 1008 DIODE DA221 TL G2070178 1- B f4
D 1009 DIODE M1FM3-5063 G2070804 1-
D 1009 DIODE M1FM3-6063 G2071090 94-
D 1009 DIODE M1FM3-6063 G2071090 130-
D 1010 DIODE 1SS400 TE61 G2070634 1- A D4
D 1011 DIODE RB551V-30 TE-17 G2070892 1- B g4
D 1012 DIODE HZU2.0BTRF G2070844 1- B g3
D 1013 DIODE HN2D01FU(TE85R.F) G2070348 1- A C4
D 1014 LED 12-215UYOC/S530-A3/TR8 G2071012 1- A F4
D 1015 LED 12-215UYOC/S530-A3/TR8 G2071012 1- A F1
D 1016 LED AA1111C-TR G2070660 1- A A2
D 1016 LED SML-512DWT86 G2071116 130- A A2
D 1017 LED AA1111C-TR G2070660 1- A B2
D 1017 LED SML-512DWT86 G2071116 130- A B2
D 1018 LED AA1111C-TR G2070660 1- A A3
D 1018 LED SML-512DWT86 G2071116 130- A A3
