Yaesu FT-60R/E - MC 1 xxx; Q 1 xxx

42
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
FT-60R/E Technical Supplement
L 1063 M.RFC 1uH LK1608 1R0K-T L1690687 1- B c2
L 1064 M.RFC 0.047uH TFL0816-47 L1690499 1- A C2
L 1065 M.RFC 0.039uH TFL0816-39 L1690498 1- A C2
L 1066 M.RFC 0.039uH TFL0816-39 L1690498 1- A D2
L 1067 M.RFC 0.22uH 2% C1608CB-R22G-RF L1691103 1- B c2
L 1068 M.RFC 0.082uH 2% C1608CB-82NG-RF L1691044 1- B c2
L 1069 M.RFC 0.082uH 2% C1608CB-82NG-RF L1691044 1- B c2
L 1070 M.RFC 0.024uH 2% C1608CB-24NG-RF L1691281 1- B c2
L 1071 M.RFC 0.022uH TFL0816-22 L1690495 1- B c2
L 1072 M.RFC 0.047uH 2% C1608CB-47NG-RF L1691040 1- B c2
L 1073 M.RFC 0.082uH 2% C1608CB-82NG-RF L1691044 1- B c2
L 1074 COIL E2 0.28-1.0-10TR L0022425 1- B b2
L 1075 COIL E2 0.35-1.6-7T-L L0022390 1- B b2
L 1076 M.RFC 1uH LK1608 1R0K-T L1690687 1- A C2
L 1077 M.RFC 1uH LK1608 1R0K-T L1690687 1- A C2
L 1078 M.RFC 1uH LK1608 1R0K-T L1690687 1- A G4
L 1079 M.RFC 1uH LK1608 1R0K-T L1690687 1- B d1
L 1080 M.RFC 1uH LK1608 1R0K-T L1690687 1- B b1
L 1081 M.RFC 0.039uH TFL0510-39N L1690818 10- A C1
L 1082 M.RFC 0.039uH TFL0510-39N L1690818 10- A C1
MC1001 MIC. ELEMENT EM-100PT M3290029 1- A D1
MC1001 MIC. ELEMENT PF0-1055P M3290045 130- A D1
Q 1001 IC NJU7231F30-TE1 G1093512 1- B c3
Q 1002 TRANSISTOR 2SB1132 T100 Q G3211327Q 1- B d3
Q 1003 TRANSISTOR 2SC4617 TL R G3346178R 1- B c3
Q 1004 TRANSISTOR 2SC4617 TL R G3346178R 1- B d3
Q 1005 TRANSISTOR DTC144EE TL G3070075 1- B f2
Q 1006 TRANSISTOR 2SC4617 TL R G3346178R 1- B d3
Q 1007 IC NJM12902V-TE1 G1093592 1- B e3
Q 1008 IC TDA7233D-TR G1091112 1- B b2
Q 1009 TRANSISTOR 2SC4617 TL R G3346178R 1- B c4
Q 1010 TRANSISTOR DTC144EE TL G3070075 1- B c4
Q 1011 TRANSISTOR 2SB1132 T100 Q G3211327Q 1- A E3
Q 1012 TRANSISTOR 2SC4617 TL R G3346178R 1- B c3
Q 1014 TRANSISTOR DTC144EE TL G3070075 1- A E3
Q 1015 TRANSISTOR 2SC4617 TL R G3346178R 1- A E2
Q 1016 IC S-80848CNNB-B89-T2 G1094012 1- A E3
Q 1017 TRANSISTOR 2SC4617 TL R G3346178R 1- A E3
Q 1018 TRANSISTOR DTA144EE TL G3070074 1- B d3
Q 1019 IC NJM12902V-TE1 G1093592 1- B e4
Q 1020 IC NJM12902V-TE1 G1093592 1- B f4
Q 1021 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 1022 TRANSISTOR DTC144EE TL G3070075 1- B e4
Q 1023 TRANSISTOR DTC144EE TL G3070075 1- B e4
Q 1024 TRANSISTOR DTC144EE TL G3070075 1- B d4
Q 1025 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- B g3
Q 1026 TRANSISTOR 2SC4617 TL R G3346178R 1- B d4
Q 1027 TRANSISTOR DTA144EE TL G3070074 1- B e3
Q 1028 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 1029 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 1030 IC BU2090FS-E2 G1092187 1- B e3
Q 1031 IC HD64F2266TF13V(FLASH) G1093813 1- A F3
Q 1032 TRANSISTOR DTA144EE TL G3070074 1- A F3
Q 1033 TRANSISTOR 2SC4617 TL R G3346178R 1- B b3
Q 1034 IC AT24C256BN-SH-T G1093837 1- B b3
Q 1034 IC R1EX24256ASAS0I G1094758 130- B b3
Q 1035 TRANSISTOR 2SC4617 TL R G3346178R 1- B a3
Q 1036 TRANSISTOR 2SB1132 T100 Q G3211327Q 1- B a3
Q 1037 IC MB15A01PFV1-G-BND-EFE1 G1092545 1- B e2
Q 1038 TRANSISTOR 2SA1774 TL R G3117748R 1- B e2
Q 1039 TRANSISTOR DTC144EE TL G3070075 1- B e2
Q 1040 TRANSISTOR 2SC5006-T1 G3350068 1- B e1
Q 1041 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- B f2
Q 1042 TRANSISTOR DTC144EE TL G3070075 1- B g1
Q 1043 TRANSISTOR DTA144EE TL G3070074 1- B g1
Q 1044 IC TA31136FNG(EL) G1091605 1- B g1
Q 1044 IC AA32416 G1094857 130- B g1
Q 1045 TRANSISTOR 2SC4617 TL R G3346178R 1- B g2
Q 1046 TRANSISTOR 2SC4617 TL R G3346178R 1- B g3
Q 1047 TRANSISTOR 2SC4617 TL R G3346178R 1- B g3
Q 1048 TRANSISTOR 2SC4617 TL R G3346178R 1- B f3
Q 1049 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- B f1
Q 1050 TRANSISTOR DTC144EE TL G3070075 1- B d3
