Yale MSW030-F

Table 9. Battery Specifications for MSW030-F
Battery Type
Number
of Cells
Cell
Size
Plates
per
Cell
Capacity
6 Hour Rate Battery Dimensions Weight
Width "X" Length "Y" Height
kwh (amp hr) mm (in.) mm (in.) mm (in.) kg (lb)
GNB PalletPro®
Battery Pack
with 25 Amp
Charger
- - - 4.4 (195) 693 (27.3) 191 (7.5 671 (26.4) 170 (375)
Battery Power
Pack GP 20
Amp Charger
- - - 3.9 (170) 660 (25.9) 198 (7.8) 611 (24.0) 122 (270)
Industrial
12 75 5 3.5 (150) 643 (25.3 163 (6.4) 592 (23.3 186 (410)
12 85 5 3.9 (170) 643 (25.3 163 (6.4) 592 (23.3 193 (425)
12 100 5 4.6 (200) 643 (25.3 163 (6.4) 668 (26.3) 213 (470)
12 75 7 5.2 (225) 653 (25.7) 224 (8.8) 592 (23.3 245 (540)
12 85 7 6.0 (255) 653 (25.7) 224 (8.8) 592 (23.3 259 (570)
NOTE:
Steel tray with cover required for all batteries.
Battery connector type is 175 Amp RED (Gray is optional).
Cable lead position "B".
20" Cable length.
Maximum cable gauge of 1/0.
Maintenance
86
