Table 6. (See Figure 17 Through Figure 20) (Continued)
Item No. Item
8 Hr/
1 Day
250 Hr/
6 Mo
500 Hr/
6 Mo
1000 Hr/
6 Mo
2000 Hr/
1 Yr
4000 Hr/
2 Yr
Procedure
or Quantity
Specification
NOTE 1: Check fuel system for leaks prior to any service or maintenance activity.
NOTE 2: Heavy-duty or high-temperature operations require more frequent checks.
NOTE 3: Heavy-duty or contaminated applications will require hydraulic oil change at 2000 hours.
NOTE 4: Change engine oil and filter after the first 100 hours of operation. Change transmission oil filter after first 500 hours of operation.
NOTE 5: Recommended service intervals are based on a normal application in a clean environment. Applications involving contaminated environments such
as high levels of airborne debris (dust and waste paper); chemical or abrasive compounds; poor ground conditions; intensive usage at high performance
levels; or other abnormal conditions will require more frequent servicing. At your request, your Yale dealer will advise you of the appropriate service intervals
based on an application survey.
NOTE 6: In dirty or dusty environments, replace at 1000 hours or as needed.
NOTE 7: Check fuel injectors at 5000 hours or 7 years.
NOTE 8: Multipurpose grease with 2 to 4% Molybdenum Disulfide.
NOTE 9: Vehicles used in paper application require regular inspection and cleaning to minimize the risk of fire. This should be done at least once every 8
hours or more frequently depending upon operating environment. Use compressed air and steam clean as necessary.
NOTE 10: Lubricate mast every 3 months if unit has less than 1000 hours.
NOTE 11: Lubricate at first sign of visible surface rust.
X = Check C = Change L = Lubricate CIL = Check indicator light during operation
Maintenance Schedule
133
