Forks, Adjust
NOTE: During the adjustment of the forks, the heel of the
forks should not be touching the ground.
The forks are connected to the carriage by hooks and lock
pins. See Figure 31 and Figure 32. The lock pins are installed
through the top fork hooks and fit into slots in the top carriage
bar. If pin does not remain engaged in carriage slot, replace
with new pin. Adjust the forks as far apart as possible for
maximum support of the load. Hook forks will slide along the
carriage bars to adjust for the load to be lifted. Raise the lock
pin in each fork to slide the fork on the carriage bar. Make
sure the lock pin is engaged in the carriage bar to lock the
fork in position after the width adjustment is made.
Maintenance
155
