2. Put the tire tool into the slot
between the lock ring and the
wheel rim. Remove the lock
ring and side flange.
Turn the tire over. Put a sup-
port under the wheel rim.
Make sure the wheel rim is at
least 150 to 200 mm (6 to
8 in.) from the bed of the press.
3. Put the cage in position on
the tire. Use the press to push
the tire from the wheel rim.
Install Tire on Wheel
WARNING
Damage to tire and wheel
assembly and injury or
death can occur if you do
not do the following proce-
dures:
• Clean and inspect all parts of the wheel before instal-
ling the tire.
• DO NOT use any damaged or repaired wheel parts.
• Make sure that all parts of the wheel are the correct
parts for the wheel assembly.
• DO NOT mix parts between different types or manu-
facturers of wheels.
• DO NOT mix type of tires, type of tire tread, or wheel
assemblies of different manufacturers on any one lift
truck.
Maintenance
190
