Legend for Figure 5
1. LPG TANK WARNING
2. FLAMMABLE LP-GAS
3. EITHER WARNING (DIESEL ONLY)
4. OVERHEAD GUARD LABEL
5. WARNING, OPERATION
6. TIPOVER WARNING
7. MAST WARNING
8. WARNING FOR PARKING BRAKE
9. UL LABEL
10. BRAKE FLUID WARNING (PNEUMATIC
TRUCKS ONLY)
11. RADIAL TIRES AND WHEELS
(PNEUMATIC TIRES ONLY)
12. NO ONE ON OR UNDER FORKS
13. UNLEADED FUEL LABEL (NOT SHOWN)
14. DIESEL FUEL LABEL (NOT SHOWN)
15. NAMEPLATE
16. TRANSMISSION LABEL (EXAMPLE
ONLY)
17. DRIVE TRAIN PROTECTION CAUTION
18. PINCH POINT WARNING
19. LOCKING GAS SPRING
20. HOOD OPENING CAUTION
21. LIFT AND TILT LABEL
22. NO RIDERS
23. STABILITY SYSTEM LABEL (ON BOTH
SIDES OF TRUCK)**
24. SPLIT WHEEL WARNING (PNEUMATIC
TIRES ONLY)
25. FAN WARNING
26. ANTIFREEZE WARNING
27. BORON-FREE LABEL
28. OPTIONAL FIRE SAFETY RATING (NOT
SHOWN)
29. SOOT TRAP WARNING (DIESEL ONLY)
(NOT SHOWN)
Display Switch Cluster
WARNING
If any of the instruments, levers, or pedals do not operate
as described in the following tables, report the problem
immediately. DO NOT operate the lift truck until the prob-
lem is corrected.
NOTE: On the lift truck models covered in this manual, the
left side (see Figure 6) of the Display Switch Cluster does not
perform any functions.
Display Switch Cluster – Right-Side Display
Inputs
The lift trucks covered in this manual can have several dif-
ferent options and configurations. Depending on the equip-
ment on the lift truck, warning and indicator lights on the right
side of the Display Switch Cluster will vary and the truck may
not contain all the warning and indicator lights shown in Fig-
ure 7 and Table 1.
Model Description
23
