WARNING
Do not sit or stand by the safety cage. Do not use a ham-
mer to try and correct the position of the side flange or
lock ring when the tire has air pressure greater than
20 kPa (3 psi) of air pressure to the tire.
1. Put the tire in a safety cage. See Figure 40.
2. Add 20 kPa (3 psi) of air pressure to the tire.
3. Check that all wheel parts are correctly installed. Hit the
lock ring lightly to make sure that it is in the seat.
Figure 40. Add Air to Tires With Tube
4. If installation is correct, add air pressure to the tire to the
specified pressure. See Nameplate.
5. Check that all wheel parts are correctly installed. If instal-
lation is not correct, remove all of the air pressure from the
tire. Remove the valve core to make sure all of the air pres-
sure has been removed and then make adjustments. The
clearance at the ends of the lock ring will be approximately
Maintenance
181
