Table 2. Instruments – Warning and Indicator Lights (See Figure 8) (Continued)
Item No. Item Function
15 Warning Light,
Fuel Level
Indicator
CAUTION
Do not allow the lift truck to run out of LPG. Damage to the catalytic converter
can result.
NOTE: For LPG trucks, see label on dash to identify how your truck is equipped.
This red indicator light will illuminate when the fuel level is low.
For gasoline and diesel trucks: The light first illuminates when there is 1/16th of fuel
left in the tank.
For LPG Trucks with LPG pressure switch: The light illuminates when there is 30
seconds to 3 minutes of operation remaining.
For LPG trucks equipped with the Premium Low Fuel Sensor: The light illuminates
when there is 10 to 20 minutes of operation remaining. An audible alarm will sound
every 4 minutes when the red light is illuminated.
16 Indicator Light Cold
Start (Diesel Only)
This amber indicator light will illuminate for up to 10 seconds after engine startup
signifying that the glow plugs are functioning properly at temperatures up to 80 °C
(176 °F) coolant temperature.
Model Description
39
