Table 4. Auxiliary Control Levers

Function

Direction of Movement

Load or Equipment Control Lever

1. REACH Retract/Extend Backward/Forward

2. SIDESHIFT Right/Left Backward/Forward

3. PUSH-PULL Backward/Forward Backward/Forward

4. ROTATE Clockwise/Counterclockwise Backward/Forward

5. UPENDER Up/Down Backward/Forward

6. SCOOP Up/Down Backward/Forward

7. LOAD STABILIZER Down (Clamp)/Up (Release) Backward/Forward

8. SWING (FORKS) Right/Left Backward/Forward

9. FORK SPREAD Together/Apart Backward/Forward

10. CLAMP Clamp/Release Backward/Forward
