5-7
GB
Procedure
1) Remove the top cowling.
2) Remove the starter/flywheel cover by
removing the bolts.
NOTE:
On a model equipped with the start-in-
gear protection device (cable), disconnect
the cable from the starter.
208025
3) Prepare the engine for starting. See
“STARTING ENGINE” for procedures.
Be sure the engine is in Neutral and
that the lanyard is attached to the
engine stop switch.
On the electric start model the main
switch must be on if the main switch
is equipped.
4) To start the engine with emergency
starter rope, insert the knotted end of
the rope into the notch in the flywheel
rotor and wind the rope several turns
clockwise. Then, give a strong pull
straight out to crank the engine.
Repeat if necessary.
