Outboard Rigging Guide - 2001
CONTROL BOX APPLICATIONS
NOTE:
*V4’s include 115, 130
** V6’s include DX150, V150, VX150, VZ150, Z150, SX150, Z175, VZ175, SX200, VX200, VZ200, Z200,
SX225, VX225, SX250, VX250
O = Optional
Or = Optional Recommended
Sc = Standard in Crate
Sk = Standard in Standard Rigging Kit, if ordered with engine.
U = User’s Choice
T8P
F25T F80 LF115
F40T F100 L130
F15E 40T C40T~ F115 To
F9.9 9.9 25 F25E To To V4* L250
Description Part Number T9.9 15 30 40E 90 C115 V6** LX250
701 Pull - No Elec. 701-48101-51-00 O O
701 Push - No Elec. 701-48130-02-00 O
703 Pull 703-48230-12-00 Or Or
7 Pin/Choke 703-48240-12-00 Or
703 Push 703-48207-15-00 U U Sk Sk Sk Sk
10 Pin/Main Sw Except Except
Choke F25 F25
Single Binnacle 704-48205-13-00 Sk Sk Sk Sk
Dual Binnacle 704-48207-31-00 O O O Sk
Flush Side Mnt 90° 6X0-48206-11-00 O O O O
7-Pin to 10-Pin 703-8258A-00-00 O O
Adapter
