1-14
Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
F25TLRZ
Part Number Description Qty
LIT-18626-04-28 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
90201-10M20-00 Plate Washer 2
90201-10120-00 Plate Washer 2
90185-09M01-00 Nylon Lock Nut 2
6G5-43145-00-00 Clamp Bracket Cap 1
663-48344-00-00 Cable End (Remote Control) 2
90468-18008-00 Clip 2
90101-12M65-00 Bolt 4
92995-12200-00 Washer 8
90201-12426-00 Plate Washer 4
95380-12600-00 Nut 8
62Y-42727-00-00 Grommet 1
6H3-48538-00-00 Cable Clamp 1
90185-10051-00 Nylon Lock Nut 2
6E5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
65W-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 1
90387-10M42-00 Collar 1
90201-10M63-00 Plate Washer 1
90101-09M01-00 Bolt 1
30ELHZ
Part Number Description Qty
LIT-18626-04-13 Owner’s Manual 1
6G5-2818N-31-00 Caution Tag 1
6Y1-24306-51-00 Fuel Pipe Complete 1
90101-10M58-00 Bolt 4
92995-10600-00 Washer 8
90201-12426-00 Plate Washer 4
95380-10600-00 Nut 8
30MSHZ/MLHZ
Part Number Description Qty
LIT-18626-04-13 Owner's Manual 1
6Ll5-2818N-31-00 Caution Tag 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
T25TLRZ
Part Number Description Qty
LIT-18626-04-28 Owner's Manual 1
677-15780-00-00 Emergency Starter Ass'y 1
6Y1-24306-53-00 Fuel Pipe Complete 1
663-48344-00-00 Cable End (Remote Control) 2
6H3-48538-00-00 Cable Clamp 1
6G5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
65W-61351-00-00 Steering Link Rod 1
90201-12426-00 Plate Washer 4
90468-18008-00 Clip 2
92995-10600-00 Washer 8
92995-12200-00 Washer 8
95380-12600-00 Nut 8
6G5-43145-00-00 Clamp Bracket Cap 1
90185-10051-00 Nylon Nut 2
90185-09M01-00 Nylon Nut 2
90101-12M65-00 Bolt 4
90201-10M20-00 Plate Washer 2
