Yamaha 684CS - Page 52

1-15
Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
30ELRZ
Part Number Description Qty
LIT-18626-04/13 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
6Y1-24306-51-00 Fuel Pipe Complete 1
90101-10M58-00 Bolt 4
92995-10600-00 Plate Washer 8
90201-12426-00 Plate Washer 4
95380-10600-00 Nut 8
6G8-26364-00-00 Wire End 2 1
6G8-26363-00-00 Wire End 1 1
689-61351-01-00 Steering Link Rod 1
90170-09M03-00 Nut 1
90387-10M42-00 Collar 1
90201-10M63-00 Plate Washer 1
6E5-61355-00-00 Bolt 1
90201-10M20-00 Plate Washer 2
90185-09M01-00 Nylon Lock Nut 2
6E5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
F30TLRZ
Part Number Description Qty
LIT-18626-04/29 Owner's Manual 1
677-15780-00-00 Emergency Starter Ass’y1
6Y1-24306-53-00 Fuel Pipe Complete 1
6G5-43145-00-00 Clamp Bracket Cap 1
67C-48344-00-00 Cable End (Remote Control) 2
90101-12M65-00 Bolt 4
90201-12426-00 Plate Washer 4
90468-18008 Clip 2
92995-12200-00 Washer 8
95380-12600-00 Nut 8
90185-09M01-00 Nylon Nut 2
90201-10M20-00 Plate Washer 2
93210-16275-00 O-Ring 1
6E5-43145-01-00 Clamp Bracket Cap 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
65W-61351-00-00 Steering Link Rod 1
40TLRZ
Part Number Description Qty
LIT-18626-04-14 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
6E5-43145-01-00 Clamp Bracket Cap 1
63D-61351-00-00 Steering Link Rod 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
90101-12M65-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
90201-10M20-00 Plate Washer 2
92995-12200-00 Washer 8
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
F40MLHZ
Part Number Description Qty
LIT-18626-04-29 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
67C-48344-00-00 Remote Control 1 Cable End 2
90468-18008-00 Clip 2
90101-12M65-00 Bolt 4
90185-10051-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
92995-12200-00 Plate Washer 8
95380-12600-00 Nut 8
