Yamaha 684CS - Page 53

1-16
Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
C40TLRZ, C50TLRZ
Part Number Description Qty
LIT-18626-04-14 Owner's Manual 1
6R6-2818N-30-00 Caution Tag 1
689-2818N-30-00 Caution Tag 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
90101-12M65-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
6E5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
63D-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 1
90101-09M01-00 Bolt 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
90201-12426-00 Plate Washer 4
92995-12200-00 Plate Washer 8
95380-12600-00 Nut 8
F40TLRZ
Part Number Description Qty
LIT-18626-04-29 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
90101-12M65-00 Bolt 4
90201-12426-00 Plate Washer 4
92995-12200-00 Plate Washer 8
95380-12600-00 Nut 8
67C-48344-00-00 Cable End 2
90468-18008-00 Clip 2
65W-61351-00-00 Steering Link Rod 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
6E5-43145-01-00 Clamp Bracket Cap 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
93210-16275-00 O-Ring 1
F50TLRZ
Part Number Description Qty
LIT-18626-04-30 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
6G8-26363-00-00 Wire End 1 2
62Y-42727-00-00 Grommet 1
6E5-43145-01-00 Clamp Bracket Cap 1
6G5-43145-00-00 Clamp Bracket Cap 1
62Y-48538-00-00 Cable Clamp 1
63D-61351-00-00 Steering Link Rod 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-12426-00 Plate Washer 4
90387-10M42-00 Collar 1
90101-12M65-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
90201-10M20-00 Plate Washer 2
92995-12200-00 Plate Washer 8
90201-16275-00 Plate Washer 1
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
50TLRZ
Part Number Description Qty
LIT-18626-04-14 Owner's Manual 1
677-15780-00-00 Emergency Starter Ass'y 1
6G5-2818N-31-00 Tag Caution 1
6Y1-24306-53-00 Fuel Pipe Complete 1
90101-12M65-00 Bolt 4
92995-12200-00 Washer 8
90201-12426-00 Plate Washer 4
95380-12600-00 Nut 8
90201-10M20-00 Plate Washer 2
90185-09M01-00 Nylon Nut 2
6E5-43145-00-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
63D-61351-00-00 Steering Link Rod 1
90101-09M01-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
