Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
T50TLRZ
Part Number Description Qty
LIT-18626-04-30 Owner's Manual 1
64J-1819K-90-00 Set-Up Manual 1
64J-2819K-90-00 Splash Plate Install. Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
6G8-26363-00-00 Wire End 1 2
62Y-42727-00-00 Grommet 1
6E5-43145-01-00 Clamp Bracket Cap 1
6G5-43145-00-00 Clamp Bracket Cap 1
64J-45168-00-00 Splash Plate 1
62Y-48538-00-00 Cable Clamp 1
63D-61351-00-00 Steering Link Rod 1
90101-09M01-00 Bolt 4
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
90101-12M65-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
90201-10M20-00 Plate Washer 2
92995-12200-00 Plate Washer 8
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
6Y5-82117-00-00 Lead Wire 1
64D-82553-70-00 Extension Lead Wire (7M) 1
6Y5-83553-00-00 Lead Wire 1
6Y5-83670-11-00 Trim Meter Ass'y 1
60TLRZ
Part Number Description Qty
LIT-18626-04-14 Owner's Manual 1
677-15780-00-00 Emergency Starter Ass’y1
6G5-2818N-31-00 Caution Tag 1
6Y1-24306-53-00 Fuel Pipe Complete 1
90101-12M65-00 Bolt 4
92995-12200-00 Washer 8
90201-12426-00 Plate Washer 4
95380-12600-00 Nut 8
90201-10M20-00 Plate Washer 2
90185-09M01-00 Nylon Nut 2
6E5-43145-00-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
688-61351-00-00 Steering Link Rod 1
6E5-61355-00-00 Bolt 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
70TLRZ
Part Number Description Qty
LIT-18626-04-30 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6G5-2818N-31-00 Caution Tag 1
6Y1-24306-51-00 Fuel Pipe Complete 1
6E5-43145-01-00 Clamp Bracket Cap 1
90101-12M65-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
90201-12200-00 Plate Washer 8
90201-10M20-00 Plate Washer 2
95380-12600-00 Nut 8
93210-16275-00 O-Ring 1
688-61351-10-00 Rod 1
90170-09M03-00 Nut 1
90201-10M63-00 Plate Washer 1
6E5-61355-00-00 Bolt 1
90387-10M42-00 Collar 1
