Yamaha 684CS - Page 55

1-18
Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
C60TLRZ, C70TLRZ, C90TLRZ
Part Number Description Qty
LIT-18626-04-34 Owner's Manual 1
6R6-2818N-30-00 Caution Tag 1
689-2818N-30-00 Caution Tag 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
688-61351-10-00 Steering Link Rod 1
6E5-43145-01-00 Clamp Bracket Cap 1
6E5-61355-00-00 Bolt 1
90101-12M65-00 Bolt 4
90170-09M03-00 Nut 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
90201-10M63-00 Plate Washer 1
90201-12426-00 Plate Washer 4
90387-10M42-00 Collar 1
92995-12200-00 Plate Washer 8
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
90TLRZ
Part Number Description Qty
LIT-18626-04-34 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
6E5-43145-01-00 Clamp Bracket Cap
688-61351-10-00 Steering Link Rod 1
6E5-61355-00-00 Bolt 1
90101-12M65-00 Bolt 4
90170-09M03-00 Nut 1
90185-09M01-00 Nylon Lock Nut 2
90201-12426-00 Plate Washer 4
90201-10M20-00 Plate Washer 2
90201-10M63-00 Plate Washer 1
90387-10M42-00 Collar 1
92995-12200-00 Plate Washer 8
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
F80TLRZ, F100TLRZ
Part Number Description Qty
LIT-18626-04-31 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y2-24307-40-00 Fuel Pipe Complete 1
67F-82105-00-00 Battery Cable 1
67F-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 1
90387-10M42-00 Collar 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
90201-10M63-00 plate Washer 1
6E5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
90201-13M01-00 Plate Washer 8
90201-12M05-00 Plate Washer 4
90101-09M01-00 Bolt 1
90101-12M03-00 Bolt x 115 4
F100TXRZ
Part Number Description Qty
LIT-18626-04-31 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y2-24307-40-00 Fuel Pipe Complete 1
67F-82105-00-00 Battery Cable 1
67F-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 1
90387-10M42-00 Collar 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
90201-10M63-00 plate Washer 1
6E5-43145-01-00 Clamp Bracket Cap 1
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
90201-13M01-00 Plate Washer 8
90201-12M05-00 Plate Washer 4
90101-09M01-00 Bolt 1
90101-12M03-00 Bolt x 115 4
