I/O DEVICE window (I/O page)
 RSio64-D display
If the card’s internal sampling rate converter function is enabled when an MY8-AE96S mini-
YGDAI card is inserted into the RSio64-D, the display will appear as shown below.
1 Card name
“AE96S (w/SRC)” is displayed.
If the card’s internal sampling rate converter function is disabled, “MY8-AE96S” is
displayed.
2 WCLK display
“CARD” is displayed.
If the card’s internal sampling rate converter function is disabled, “SLOT” is displayed.
Setup
Added supported devices
The following devices are now supported: Audinate Dante-MY16-AUD2; d&b audiotechnik
DS10; Shure AXT400, QLXD4, and ULXD4. They can be mounted on the DEVICE MOUNT
page in the DANTE SETUP window.
NOTE
ShureAXT400, QLXD4, and ULXD4 can be mounted only when online.
1 2

Yamaha CL Series Specifications

General

Dante Network	Yes
Touch Screen	Yes
Type	Digital Mixing Console
Control Surface	Yes
Mixing Channels	CL5: 72, CL3: 64, CL1: 48
Local I/O	CL5: 8 in / 8 out, CL3: 8 in / 8 out, CL1: 8 in / 8 out
USB Recording	Yes
EQ	4-band parametric EQ per channel
Effects	Yes
DAW Control	Yes
Word Clock	Yes
Input Channels	CL5: 72, CL3: 64, CL1: 48
Output Channels	CL5: 34, CL3: 34, CL1: 34
Sampling Rate	44.1kHz, 48kHz, 88.2kHz, 96kHz
Connectivity	Dante, USB
Recallable Scenes	Yes
Expandability	Yes
