57
English
SELECTING AND EDITING PROGRAM PARAMETERS
This adjustment can be made only by using the remote control transmitter watching the monitor screen or the display panel.
Note
It is recommended to watch the monitor screen for making adjustments more easily than to watch the display panel.
1 Set the PARAMETER/SET MENU switch to the
PARAMETER position.
Note: Be sure to use the remote control transmitter
with the lid open.
2 Turn your monitor on. If the currently selected type of
display is not the full display, press the ON SCREEN
display key to call the full display.
3 If no DSP program is selected, select a desired
program.
The selected program name and its parameters will be
displayed on the monitor screen. The arrow-shaped
cursor points to the subprogram name.
4 Select a desired subprogram.
Press the button for
the currently selected
program once or more.
5 Select the parameter which you want to edit.
6 Change the value on the selected parameter to create
the effect you want.
“+” increases the value of the selected parameter, and “–”
decreases the value of the selected parameter. In both cases
you can hold the key down for continuous incrementing or
decrementing.
The display will pause for a moment at the initial value of the
parameter as a reminder. (On the monitor screen,
*
mark at
the head of parameter name disappears at the initial value of
the parameter.)
Notes
●
For details about parameters, refer to pages 58 to 60.
●
Parameter edits made in this way will remain in effect even
with power cut due to power failure or the power plug
disconnected from the AC outlet for up to about two weeks,
after which all parameters, as well as other adjustments or
setting changes on this unit, will return to their initial values
or conditions.
....
....
....
....
...
To Next Page
