60
DSP-A5
P. C. B. POWER
Schm
Ref
PART NO. Description
✻ New Parts
✻ New Parts
Schm
Ref
PART NO. Description
V4801900 P.C.B. POWER(B)
V4802000 P.C.B. POWER(G)
V4802400 P.C.B. POWER(RT)
CB401 VQ045300 CN.BS.PIN 23P
CB451 Vi878600 CN.BS.PIN 8P
CB721 VQ963000 CN.BS.PIN 9P
CB722 Vi878600 CN.BS.PIN 8P
CB801 VQ960900 CN.BS.PIN 6P
CB804 VP206500 HOLDER.FUS EYF-52BCT
CB805 VG879900 CN.BS.PIN 2P
CB806 VP206500 HOLDER.FUS EYF-52BCT
CB851 VP206500 HOLDER.FUS EYF-52BCT(RT)
CB852 VP206500 HOLDER.FUS EYF-52BCT(RT)
C401 VG290600 C.EL 2.2uF 50V
C402 VP917500 C.PP 100pF 100V
C403 VP917500 C.PP 100pF 100V
C404 VG290600 C.EL 2.2uF 50V
C405 VG290600 C.EL 2.2uF 50V
C406 VG290600 C.EL 2.2uF 50V
C407 VG290600 C.EL 2.2uF 50V
C408 VG290600 C.EL 2.2uF 50V
C409 UN866100 C.EL 1uF 50V
C410 UU137100 C.EL 10uF 16V
C412 VM645200 C.PP 560pF 100V
C414 VM645200 C.PP 560pF 100V
C417 UU137100 C.EL 10uF 16V
C418 UU137100 C.EL 10uF 16V
C420 VG291300 C.EL 100uF 50V
C421 VP917500 C.PP 100pF 100V
C422 VG286200 C.EL 100uF 10V
C423 UA952100 C.MYLAR 100pF 50V
C424 VG286200 C.EL 100uF 10V
C425 VG291300 C.EL 100uF 50V
C427 Vi578700 C.EL 10uF 50V
C428 Vi578700 C.EL 10uF 50V
C430 UA952100 C.MYLAR 100pF 50V
C431 VG286200 C.EL 100uF 10V
C432 UA952100 C.MYLAR 100pF 50V
C433 VG286200 C.EL 100uF 10V
C435 Vi578700 C.EL 10uF 50V
C436 VJ599100 C.CE.TUBLR 0.1uF 50V
C451 VG291500 C.EL 330uF 50V
C452 VG291500 C.EL 330uF 50V
C453 UR749220 C.EL 2200uF 25V
C454 VE326000 C.MYLAR.ML 0.1uF 50V
C455 UR749470 C.EL 4700uF 25V
C456 VE326000 C.MYLAR.ML 0.1uF 50V
C457 VS745400 C.POL.MTL 0.1uF 100V
C458 UR73A100 C.EL 10000uF 16V
C461 VE326000 C.MYLAR.ML 0.1uF 50V
C462 VE326000 C.MYLAR.ML 0.1uF 50V
C463 UR73A100 C.EL 10000uF 16V
C464 VS745400 C.POL.MTL 0.1uF 100V
C721 VG291200 C.EL 47uF 50V
C722 VG291200 C.EL 47uF 50V
C723 VG287600 C.EL 100uF 25V
C724 VG288500 C.EL 10uF 50V
C725 VG287600 C.EL 100uF 25V
C726 VG288500 C.EL 10uF 50V
C727 VG291200 C.EL 47uF 50V
C728 VG291200 C.EL 47uF 50V
C729 UR838100 C.EL 100uF 16V
C730 UR838100 C.EL 100uF 16V
C731 UR847100 C.EL 10uF 25V
C732 UR838100 C.EL 100uF 16V
C733 UR847100 C.EL 10uF 25V
C734 UR847100 C.EL 10uF 25V
C801 FG613100 C.CE 1000pF 50V(RT)
C802 VJ599100 C.CE.TUBLR 0.1uF 50V
C804 VL884600 C.PP 0.01uF 100V
C805 UR896470 C.EL 4.7uF 100V(RT)
C806 Vi716700 C.MYLAR 0.01uF 50V
C807 V3501400 C.CE.SAFTY 0.01uP 275V
C808 UR848220 C.EL 220uF 25V(RT)
D401 VM974200 DIODE.ZENR HZS5C2TD 5.0V
D451 VQ379300 DIODE.BRG S1VB20 1.0A 200V
D452 VQ379300 DIODE.BRG S1VB20 1.0A 200V
D453 V4269600 DIODE.BRG D2SBA20 1.5A 200V
D721 VM976300 DIODE.ZENR HZS242TD 24V
D722 VM976300 DIODE.ZENR HZS242TD 24V
D801 VD631600 DIODE 1SS133,176,HSS104
D803 VM975600 DIODE.ZENR HZS12B2TD 12V(RT)
D804 VV307700 DIODE 1N4002S
D805 VV307700 DIODE 1N4002S
D806 VV307700 DIODE 1N4002S
D807 VV307700 DIODE 1N4002S
F802 VS823300 FUSE T8.0A 125V
F851 KB000790 FUSE T4.0A 250V(RT)
HS801 VR506800 HEAT.SINK PUH16-25(RT)
IC401 XA987A00 IC NJM2068D-D
IC402 XA987A00 IC NJM2068D-D
IC403 XA987A00 IC NJM2068D-D
IC404 XF494A00 IC LB1641
IC721 XJ608A00 IC NJM7812FA
IC722 XD343A00 IC NJM79M12FA
IC723 XJ604A00 IC NJM78M05FA
IC724 XE436A00 IC NJM79M05FA
IC725 XJ607A00 IC NJM7805FA 5V
PN451 V3750200 PIN L=70
Q721 iC1815I0 TR 2SC1815 Y
Q722 iA1015I0 TR 2SA1015 Y
Q801 iC174020 TR 2SC1740S R,S
Q802 VR510800 TR 2SD2396 J,K(RT)
R411 VP940200 R.MTL.OXD 47Ω 1W
R412 VP940200 R.MTL.OXD 47Ω 1W
R435 HV754100 R.CAR.FP 10Ω 1/4W
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
!
!
!
!
✻
✻
!
!
!
!
✻
!
!
!
!
!
!
!
