Yamaha DSP-A5 Service Manual

61
DSP-A5
P. C. B. POWER & P. C. B. MAIN
Schm
Ref
PART NO. Description
✻ New Parts
✻ New Parts
Schm
Ref
PART NO. Description
R451 HV753100 R.CAR.FP 1Ω 1/4W
R452 HV753100 R.CAR.FP 1Ω 1/4W
R725 HV753100 R.CAR.FP 1Ω 1/4W
R726 HV753100 R.CAR.FP 1Ω 1/4W
R727 HV755100 R.CAR.FP 100Ω 1/4W
R728 HV755100 R.CAR.FP 100Ω 1/4W
R729 HV753100 R.CAR.FP 1Ω 1/4W
R730 VP939500 R.MTL.FLM 1Ω 1W
R731 VP939600 R.MTL.FLM 2.2Ω 1W
R802 HV756560 R.CAR.FP 5.6KΩ 1/4W(RT)
R803 HV756560 R.CAR.FP 5.6KΩ 1/4W(RT)
RY801 V2712300 RELAY DC SDT-S-112LMR
ST801 BB071360 SCR.TERM 8.3x13
SW851 VA961800 VOLT.SELCT ESE-37247-F(RT)
T801 XW607A00 TRANS.PWR (RT)
TE801 V4746500 OUTLET.AC 3P(RT)
VR401 VV613500 VR A100KΩ
EP600140 SCR.BND.HD 3x10 MFZN2-BL(RT)
V4802700 P.C.B. MAIN(RT)
V4802800 P.C.B. MAIN(BG)
CB501 VQ045000 CN.BS.PIN 20P
CB502 VQ961700 CN.BS.PIN 14P
CB503 VQ963500 CN.BS.PIN 14P
CB505 VF728200 CN.BS.PIN 10P
CB506 Vi878600 CN.BS.PIN 8P
CB507 VQ961200 CN.BS.PIN 9P
CB702 VQ584700 CN.BS.PIN 5P
CB711 VQ584700 CN.BS.PIN 5P
CB751 Vi878600 CN.BS.PIN 8P
CB752 VQ962700 CN.BS.PIN 6P
C501 VK534000 C.PP 220pF 200V
C502 Vi377400 C.EL 4.7uF 63V
C503 V2290000 C.EL 22uF 63V
C504 UU137100 C.EL 10uF 16V
C505 UU137100 C.EL 10uF 16V
C506 V5618600 C.EL 10uF 25V
C0507 UU138100 C.EL 100uF 16V
C508 Vi578700 C.EL 10uF 50V
C509 Vi578700 C.EL 10uF 50V
C510 VQ645600 C.MYLAR 100pF 50V
C511 VQ462600 C.MYLAR 220pF 50V
C512 VQ645600 C.MYLAR 100pF 50V
C513 VQ462600 C.MYLAR 220pF 50V
C514 VQ645600 C.MYLAR 100pF 50V
C515 VQ462600 C.MYLAR 220pF 50V
C516 UA952100 C.MYLAR 100pF 50V
C517 UA952220 C.MYLAR 220pF 50V
C518 UA952100 C.MYLAR 100pF 50V
C519 UA952220 C.MYLAR 220pF 50V
C520 FU451150 C.MICA 15pF 500V
C521 VG291300 C.EL 100uF 50V
C522 VP918000 C.PP 3300pF 100V
C523 FU451150 C.MICA 15pF 500V
C524 VG291300 C.EL 100uF 50V
C525 VP918000 C.PP 3300pF 100V
C526 FU451150 C.MICA 15pF 500V
C527 VG291200 C.EL 47uF 50V
C528 VP918000 C.PP 3300pF 100V
C529 VR516400 C.CE 15pF 500V
C530 V4578900 C.EL 47uF 35V
C531 UA953330 C.MYLAR 3300pF 50V
C532 VR516400 C.CE 15pF 500V
C533 V4578900 C.EL 47uF 35V
C534 UA953330 C.MYLAR 3300pF 50V
C535 VG291200 C.EL 47uF 50V
C536 VG291200 C.EL 47uF 50V
C537 VG291200 C.EL 47uF 50V
C538 VG291200 C.EL 47uF 50V
C539 VG291200 C.EL 47uF 50V
C540 V2290000 C.EL 22uF 63V
C541 VS759000 C.PP 150pF 630V
C542 VG287500 C.EL 47uF 50V
C543 V5618900 C.EL 47uF 25V
C544 VS759000 C.PP 150pF 630V
C545 VS759000 C.PP 150pF 630V
C546 VT898000 C.MYLAR 0.1uF 100V
C547 V5618900 C.EL 47uF 25V
C548 VS759000 C.PP 150pF 630V
C549 VS759000 C.PP 150pF 630V
C550 V5618900 C.EL 47uF 25V
C551 VS759000 C.PP 150pF 630V
C552 V3872800 C.MYLAR 150pF 100V
C553 VG287500 C.EL 47uF 50V
C554 V3872800 C.MYLAR 150pF 100V
C555 V3872800 C.MYLAR 150pF 100V
C556 VG287500 C.EL 47uF 50V
C557 V3872800 C.MYLAR 150pF 100V
C558 VP918300 C.PP 0.022uF 100V
C559 VP918300 C.PP 0.022uF 100V
C560 VP918300 C.PP 0.022uF 100V
C561 UA954220 C.MYLAR 0.022uF 50V
C562 UA954220 C.MYLAR 0.022uF 50V
C563 UR866470 C.EL 4.7uF 50V
C564 VT898000 C.MYLAR 0.1uF 100V
C565 VK534000 C.PP 220pF 200V
C568 UR866470 C.EL 4.7uF 50V
C569 UR866470 C.EL 4.7uF 50V
C570 UR818220 C.EL 220uF 6.3V
C582 V2290000 C.EL 22uF 63V
C751 VS529200 C.EL 10000uF 63V
C752 VS529200 C.EL 10000uF 63V
C753 VT898000 C.MYLAR 0.1uF 100V
C754 VT898000 C.MYLAR 0.1uF 100V
C755 VK534100 C.PP 0.01uF 100V
✻
!
!
✻
!
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
!
!
✻
✻
