RX-V559/HTR-5950/DSP-AX559
10
RX-V559/HTR-5950/
DSP-AX559
■ SPECIFICATIONS / 参考仕様
■ Audio Section/オーディオ部
Minimum RMS Output Power (Power Amp. Section)/定格出力(パ
ワーアンプ部)
[RX-V559]
(20 Hz to 20 kHz, 0.06 % THD, 8 ohms)
FRONT L/R ................................................................. 95 W + 95 W
CENTER ................................................................................. 95 W
SURROUND L/R ........................................................ 95 W + 95 W
SURROUND BACK ................................................................ 95 W
[HTR-5950]
(1 kHz, 0.7 % THD, 8 ohms)
FRONT L/R ............................................................ 110 W + 110 W
CENTER ............................................................................... 110 W
SURROUND L/R ................................................... 110 W + 110 W
SURROUND BACK .............................................................. 110 W
[DSP-AX559] (J model)
(20 Hz to 20 kHz, 0.09 % THD, 6 ohms)
FRONT L/R ................................................................. 95 W + 95 W
CENTER ................................................................................. 95 W
SURROUND L/R ........................................................ 95 W + 95 W
SURROUND BACK ................................................................ 95 W
Maximum Power/実用最大出力 (EIAJ) (1 kHz, 10 % THD)
[RX-V559/HTR-5950] (R, T, K, L models)
FRONT L/R (8 ohms) ........................................................... 135 W
CENTER (8 ohms) ............................................................... 135 W
SURROUND L/R (8 ohms) ................................................... 135 W
SURROUND BACK (8 ohms) .............................................. 135 W
[DSP-AX559] (J model)
FRONT L/R (6 ohms) ........................................................... 135 W
CENTER (6 ohms) ............................................................... 135 W
SURROUND L/R (6 ohms) ................................................... 135 W
SURROUND BACK (6 ohms) .............................................. 135 W
Maximum Power Per Channel/MAXパワー (SP IMPEDANCE SET:
8 ohms Minimum/1 kHz, 0.7 % THD 4ohms)
[RX-V559/HTR-5950] (G, E models)
FRONT L/R ............................................................ 145 W + 145 W
CENTER ............................................................................... 145 W
SURROUND L/R ................................................... 145 W + 145 W
SURROUND BACK .............................................................. 145 W
IEC Power /IECパワー (1 kHz, 0.06 % THD 8ohms)
[RX-V559/HTR-5950] (G, E, L models)
FRONT L/R ............................................................ 105 W + 105 W
Dynamic Power Per Channel/ダイナミックパワー (IHF)
[RX-V559/HTR-5950]
FRONT L/R (8/6/4/2 ohms) ............................. 130/165/195/240 W
[DSP-AX559] (J model)
FRONT L/R (–/6/4/2 ohms) ................................. –/135/165/210 W
Dynamic Headroom/ダイナミックヘッドルーム (8 ohms)
[RX-V559/HTR-5950] (U, C models) ...................................... 1.6 dB
Damping Factor/ダンピングファクタ
FRONT L/R (20 Hz to 20 kHz, SPEAKER-A) ............. 120 or more
Input Sensitivity/Input Impedance / 入力感度/入力インピーダンス
CD, etc. ........................................................... 200 mV / 47 k-ohms
MULTI CH IN
FRONT L/R, CENTER, SURROUND L/R, SUBWOOFER
.................................................................. 200 mV / 47 k-ohms
Maximum Input Signal Level /最大許容入力 (1 kHz, 0.5% THD)
CD, etc. (Effect On) ................................................... 2.2 V or more
Output Level/Output Impedance / 出力電圧/出力インピーダンス
REC OUT ....................................................... 200 mV / 1.2 k-ohms
SUBWOOFER (2ch STEREO & FRONT SP: Small)
........................................................................ 4 V / 1.2 k-ohms
[RX-V559/DSP-AX559]
ZONE2 OUT .................................................. 200 mV / 1.2 k-ohms
Headphone Jack Rated Output/Impedance / ヘッドフォン出力/出
力インピーダンス
CD, etc. (1 kHz, 50 mV, 8 ohms) .................... 150 mV / 100 ohms
Frequency Response/周波数特性
CD, etc. to FRONT L/R (10 Hz to 100 kHz) .................. +0/-3.0 dB
Total Harmonic Distortion/全高調波歪率 (50 W, 8 ohms)
CD, etc. (2ch STEREO) to FRONT L/R SP OUT .... 0.06 % or less
Signal to Noise Ratio / 信号対雑音比 (IHF-A Network)
CD, etc. (Input shorted) SP OUT
250 mV ................................................................. 100 dB or more
Residual Noise/残留ノイズ (IHF-A Network)
FRONT L/R SP OUT ............................................... 150 µV or less
Channel Separation/チャンネルセパレーション
CD, etc. (Input 5.1 k-ohms shorted, 1 kHz/10 kHz)
................................................... 60 dB or more/45 dB or more
Tone Control Characteristics/トーンコントロール特性
BASS
Boost/Cut ............................................................. ±10 dB (60 Hz)
TREBLE
Boost/Cut ........................................................... ±10 dB (20 kHz)
Filter Characteristics/フィルター特性
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK SP
Small (H.P.F.)
............ fc= 40/60/80/90/100/110/120/160/200 Hz / 12 dB/oct.
SUBWOOFER (L.P.F.)
............ fc= 40/60/80/90/100/110/120/160/200 Hz / 24 dB/oct.
■ Video Section/ビデオ部
Video Signal Type (Gray Back)/ビデオ信号方式（グレーバック）
U, C, R, K, J models .............................................................. NTSC
T, A, G, E, L models ................................................................. PAL
Video Signal Type (Video Conversion)/ビデオ信号方式（ビデオコ
ンバージョン）
U, C, R, T, K, A, G, E, L, J models ............................... NTSC/PAL
Composite Video Signal Level/コンポジットビデオ信号
....................................................................... 1 Vp-p / 75 ohms
S-Video Signal Level/Sビデオ信号
Y ........................................................................... 1 Vp-p / 75 ohms
C ................................................................... 0.286 Vp-p / 75 ohms
Component Signal Level/コンポーネントビデオ信号
Y ........................................................................... 1 Vp-p / 75 ohms
Cb/Cr ................................................................ 0.7 Vp-p / 75 ohms
D4-Video Signal Level / D4端子ビデオ信号 (J model)
Y ........................................................................... 1 Vp-p / 75 ohms
Cb/Cr ................................................................ 0.7 Vp-p / 75 ohms
Video Maximum Input Level / ビデオ最大許容入力
VIDEO CONV. OFF ............................................. 1.5 Vp-p or more
Signal to Noise Ratio/信号対雑音比 ........................ 50 dB or more
Monitor Out Frequency Response/モニターアウト周波数帯域
(VIDEO CONV. OFF)
Component video signal level ..................... 5 Hz to 60 MHz, -3 dB
D4-video signal level (J model) ................... 5 Hz to 60 MHz, -3 dB
■ FM Section/FM部
Tuning Range/受信周波数範囲
U, C models ....................................................... 87.5 to 107.9 MHz
R, L models .......................... 87.5 to 108.0 / 87.50 to 108.00 MHz
T, K, A, G, E models ..................................... 87.50 to 108.00 MHz
J model ................................................................ 76.0 to 90.0 MHz
50 dB Quieting Sensitivity/50dBSN感度 (IHF) (1 kHz, 100 % Mod.)
Mono / Stereo ........................ 2.0 µV (17.3 dBf) / 25 µV (39.2 dBf)
Usable Sensitivity/実用感度 (IHF)
Mono .................................................................... 1.0 µV (11.2 dBf)
Selectivity/選択度 (at 400 kHz) ............................................. 70 dB
Signal to Noise Ratio/信号対雑音比 (IHF)
Mono / Stereo ............................................................ 76 dB / 70 dB
Harmonic Distortion/歪率 (1 kHz)
Mono/Stereo .................................................................. 0.2 / 0.3 %
Stereo Separation/ステレオセパレーション
1 kHz ...................................................................................... 42 dB
Frequency Response/周波数特性
20 Hz to 15 kHz ............................................................ +0.5 / -2 dB
Antenna Input/アンテナ入力 ......................... 75 ohms unbalanced
■ AM Section/AM部
Tuning Range/受信周波数範囲
U, C models ......................................................... 530 to 1,710 kHz
R, L models ................................. 530 to 1,710 / 531 to 1,611 kHz
T, K, A, G, E, J models ....................................... 531 to 1,611 kHz
Usable Sensitivity/実用感度 ............................................ 300 µV/m
Antenna/アンテナ入力 .............................................. Loop antenna
