Yamaha DSP-AX559 - Anode Connection Data

RX-V559/HTR-5950/DSP-AX559
45
RX-V559/HTR-5950/
DSP-AX559
17G 16G 15G 14G 13G~1G
P1 S1 S1 1-1 1-1
P2 W1 2-1 2-1
P3 W2 3-1 3-1
P4 4g 4-1 4-1
P5 1a 5-1 5-1
P6 1b 1-2 1-2
P7 1c 2-2 2-2
P8 1d 3-2 3-2
P9 1e 4-2 4-2
P10 1f 5-2 5-2
P11 1g 1-3 1-3
P12 2a 2-3 2-3
P13 2b 3-3 3-3
P14 2c 4-3 4-3
P15 2d 5-3 5-3
P16 2e 1-4 1-4
P17 2f 2-4 2-4
P18 2g 3-4 3-4
P19 3g 4-4 4-4
P20 3b 5-4 5-4
P21 3a 1-5 1-5
P22 2-5 2-5
P23 R1 3-5 3-5
P24 R2 4-5 4-5
P25 R3 5-5 5-5
P26 R4 1-6 1-6
P27 R5 2-6 2-6
P28 3-6 3-6
P29 4-6 4-6
P30 – 5-6 5-6
P31 – 1-7 1-7
P32 – 2-7 2-7
P33 – 3-7 3-7
P34 – 4-7 4-7
P35 – 5-7 5-7
P36 ––
P37 ––
● ANODE CONNECTION
