RX-V559/HTR-5950/DSP-AX559
31
RX-V559/HTR-5950/
DSP-AX559
PANEL KEY (K0/K1)
(Panel key of main unit) [Remote control code: ]
A/D of the key fails to function properly when the standard
value is deviated by ±8. In this case, check the constant of
partial pressure resistor, solder condition, etc. Refer to
table.
(Reference voltage: 5 V=100 %)
PANELKEY(K0/K1)
(本機パネルキー
キーのA/Dは基準値から±8を外れると、正常な動きをしませ
ん。下表をご覧になり、各キーの分圧抵抗の定数、ハンダ不良等
の確認をしてください。
(基準電圧:5V=100%)
IMPSW/POWERLIMIT
(インピーダンス/パワーリミッターの検出)
IMP:このモデルには適用されません。
PL パワーリミッター検出の値
IC2123ピンの入力電圧値を5V/256を基準にして表示
します。IC2123ピンの入力電圧値により、ポート(6ピ
ン)を制御します。
IMP SW/POWER LIMIT
(impedance/power limiter detection)
IMP: Not applied to these models.
PL: Power limiter detection value
The voltage value of pin No. 123 of IC2 is displayed,
using 5V/256 as standard.
The port (No. 6) output is controlled by using the in-
put voltage value of pin No. 123 of IC2.
Display (%)
0 - 6
7 - 13
14 - 21
22 - 31
32 - 41
42 - 53
54 - 63
64 - 72
73 - 80
81 - 88
89 - 95
96 - 100
K0
MAIN ZONE ON/OFF
INPUT MODE
STRAIGHT
TONE CONTROL
PRESET/TUNING
SPEAKERS B
SPEAKERS A
KEY OFF
K1
ZONE ON/OFF
ZONE CONTROL
MULTI CH INPUT
FM/AM
A/B/C/D/E
PRESET
PRESET
MEMORY
TUNING MODE
KEY OFF
Display (%)
0 - 6
7 - 13
14 - 21
22 - 31
32 - 41
42 - 53
54 - 63
64 - 72
73 - 80
81 - 88
89 - 95
96 - 100
K0
PROGRAM
PROGRAM
BASS/TREBLE -
BASS/TREBLE +
INPUT MODE
STRAIGHT
TONE CONTROL
PRESET/TUNING
SPEAKERS B
SPEAKERS A
KEY OFF
K1
MULTI CH INPUT
FM/AM
A/B/C/D/E
PRESET
PRESET
MEMORY
TUNING MODE
KEY OFF
RX-V559/DSP-AX559 HTR-5950
IMP:8 PL:245
K0:100 K1:100
