RX-V559/HTR-5950/DSP-AX559
37
RX-V559/HTR-5950/
DSP-AX559
16. IF STATUS (Input function status)
Using the sub-menu, the status data is displayed one after
another in the hexadecimal notation.
During signal processing, the status before execution of
this menu is maintained.
* Numeric values in the figure example are for reference.
<1stbyte> Digitalinput/outputsettingvalue
Upper4bits:RECOUTselected/
lower4bits:INPUTselected
Value Choice Preset name
0 NONE
1 OPT FRONT
2 OPT 1 MD/CD-R
3 OPT 2 DVD
4 OPT 3 DTV/CBL
8 COAX 1 CD
9 COAX 2
DST: DSP status
16.IFSTATUS
サブメニュー操作により、以下のステータス情報を順次16進数で
表示します。信号処理は、本メニュー実行前の状態を維持しま
す。
※図中の数値は参考例です。
DST:DSPステータス
<第1バイト>デジタル入出力設定値
上位4bitRECOUT選択/
下位4bitINPUT選択
<2nd byte> / <第2バイト>
Fs information of reproduction signal /
再生信号のFs情報
<3rd byte> / <第3バイト>
Audio code mode information of
reproduction signal /
再生信号のオーディオコードモード情報
<4th byte> / <第4バイト>
Format information of reproduction signal /
再生信号のフォーマット情報
Display Fs (kHz)
00 Analog
01 32 kHz
02 44.1 kHz
03 48 kHz
04 64 kHz
05 88.2 kHz
06 96 kHz
07 128 kHz
08 176.4 kHz
09 192 kHz
0A Unknown NRM
0B Unknown DBL
0C Unknown QUAD
0D Unknown
0E Undefined
Display Audio code
00 1+1
01 1/0
02 2/0
03 3/0
04 2/1
05 3/1
06 2/2
07 3/2
08 2/3
09 3/3
0A 3/4
0B over 6.1
0C Milti-Mono
0D Milti-PCE
0E Unknown
0F Undefined
Display Signal format
00 Analog
01 Err
10 PCM Audio
20 Digital Data
21 IEC1937
22 None PCM
23 Unknown
50 dts
51 dts-CD
52 dts 96/24
54 dts-ES (Matrix)
58 dts-ES (Discrete)
5C dts-ES (Both)
60 AAC
C0 Dolby Digital
C1
Dolby Digital Karaoke
C4 Dolby Digital EX
FF Undefined
DST:3300020000
5th byte
4th byte
3rd byte
2nd byte
1st byte
