Yamaha DSP-AX740 User Manual

RX-V740/RX-V740RDS/DSP-AX740
RX-V640/RX-V640RDS/HTR-5660/DSP-AX640/DSP-AX640SE
RX-V740/RX-V740RDS/DSP-AX740
RX-V640/RX-V640RDS/HTR-5660/DSP-AX640/DSP-AX640SE
18
F
I
G
H
K
JLMN
C
B
A
0
D
E
986547321
1 POWER (2) P.C.B.
2 POWER (3) P.C.B.
(R, T, K models only)
3 MAIN (2) P.C.B.
4 VIDEO P.C.B.
(J model only)
5 FUNCTION (8) P.C.B.
(U, C, A models only)
6 MAIN (4) P.C.B.
7 Tuner
(except DSP-AX640SE)
8 FUNCTION (7) P.C.B.
(U, C, A, B, G, L, R, T, K models only)
9 FUNCTION (5) P.C.B.
0 FUNCTION (6) P.C.B.
A FUNCTION (2) P.C.B.
B DSP P.C.B.
C FUNCTION (3) P.C.B.
D FUNCTION (4) P.C.B.
E MAIN (1) P.C.B.
F FUNCTION (1) P.C.B.
G POWER (1) P.C.B.
H MAIN (3) P.C.B.
I OPERATION (6) P.C.B.
J OPERATION (3) P.C.B.
K OPERATION (4) P.C.B.
L OPERATION (1) P.C.B.
M OPERATION (2) P.C.B.
N OPERATION (5) P.C.B.
■ INTERNAL VIEW
