Yamaha F175A - Shallow Water; Cruising in Shallow Water

Operation
66
EMU28063
Shallow water
EMU40702
Cruising in shallow water
The outboard motor can be tilted up partially
to allow operation in shallow water.
NOTICE
ECM02361
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32923
Procedure for power trim and tilt models
1. Place the remote control lever in neutral.
2. Slightly tilt the outboard motor up to the
desired position using the power trim
and tilt switch. WARNING! Using the
power trim and tilt switch on the bot-
tom cowling while the boat is moving
or engine is on could increase the risk
of falling overboard and could distract
1. Power trim and tilt switch
1. Power trim and tilt switch
1. Power trim and tilt switch
ZMU07852
DN
1
ZMU07853
DN
1
1
DN
ZMU07771
1. Cooling water inlet
1
ZMU07772
N
ZMU04588
