Yamaha F200A - Page 27

60L3D1X
22
Symbol Unit
Model
F200AET FL200AET
L1 mm (in) 651 (25.6)
L2 mm (in) 219 (8.6)
L3 mm (in) —
L4 mm (in) 673 (26.5)
L5 (X) mm (in) 59 (2.3)
L6 (X) mm (in) 1,155 (45.5)
L7 mm (in) 618 (24.3)
L8 mm (in) 230 (9.1)
L9 (X) mm (in) 52 (2.0)
L10 mm (in) 75 (3.0)
H1 (X) mm (in) 1,078 (42.4)
H2 mm (in) 727 (28.6)
H3 mm (in) 216 (8.5)
H4 (X) mm (in) 643 (25.3)
H5 mm (in) —
H6 (X) mm (in) 847 (33.3)
H7 mm (in) 361 (14.2)
H8 mm (in) 39 (1.5)
H9 mm (in) 880 (34.6)
H10 mm (in) 45 (1.8)
H11 (X) mm (in) 25 (1.0)
W1 mm (in) 317 (12.5)
W2 mm (in) —
W3 mm (in) —
W4 mm (in) —
W5 mm (in) 453 (17.8)
W6 mm (in) —
A1 Degree 32
A2 Degree 70
A3 Degree 3
T1 mm (in) 724 (28.5)
Maintenance specifications
