6Y8 Multifunction fuel
management meters
The fuel management meter has the func-
tions of fuel flow meter, total consumption
display, fuel economy display, and remaining
fuel display. The chosen display is selected
by using the “ ” (set) and “ ” (mode)
buttons as described in this section. For
more information, see the operation manual
originally supplied with the meter.
After the main switch is first turned on, all the
displays come on as a test. After a few sec-
onds, the gauge will change to normal oper-
ation.
For more information, see the operation
manual originally supplied with the meter.
1. Set button
2. Mode button
1. Speedometer
2. Fuel meter
3. Multifunction display
2
1
ZMU05436
1
2
3
ZMU05437
1. Set button
2. Mode button
1. Fuel flow meter
2. Multifunction display
2
1
ZMU05438
1
2
ZMU05439
