Operation
44
3. Disconnect the fuel line if you are using
an external fuel tank.
If the outboard motor is equipped with an en-
gine shut-off cord, the engine can also be
stopped by pulling the cord and removing the
clip from the engine shut-off switch.
EMU27855
Procedure
1. Turn the main switch to “ ” (off).
2. After stopping the engine, disconnect
the fuel line or close the fuel cock if there
is a fuel joint or a fuel cock on the boat.
3. Tighten the air vent screw on the fuel
tank cap (if equipped).
4. Remove the key if the boat will be left un-
attended.
The engine can also be stopped by pulling
the cord and removing the clip from the en-
gine shut-off switch, then turning the main
switch to “ ” (off).
EMU27864
Trimming outboard motor
EWM00741
Excessive trim for the operating condi-
tions (either trim up or trim down) can cau-
se boat instability and can make steering
the boat more difficult. This increases the
possibility of an accident. If the boat be-
gins to feel unstable or is hard to steer,
slow down and/or readjust the trim angle.
The trim angle of the outboard motor helps
determine the position of the bow of the boat
in the water. Correct trim angle will help im-
prove performance and fuel economy while
reducing strain on the engine. Correct trim
angle depends upon the combination of
boat, engine, and propeller. Correct trim is
also affected by variables such as the load in
the boat, sea conditions, and running speed.
