Operation
51
2. Place the tilt lock lever in the release/up
position.
3. Slightly tilt the outboard motor up. The tilt
support bar will lock automatically, sup-
porting the outboard motor in a partially
raised position. This outboard motor has
2 positions for shallow water cruising.
4. To return the outboard motor to the nor-
mal running position, place the remote
control lever / gear shift lever in neutral.
5. Place the tilt lock lever in the lock/down
position, then slightly tilt the outboard
motor up until the tilt support bar auto-
matically returns to the free position.
6. Slowly lower the outboard motor to the
normal position.
EMU32862
Power tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
ECM00261
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32953
Procedure for power tilt models
1. Place the remote control lever in neutral.
U60R79E0.book Page 51 Wednesday, December 18, 2013 1:32 PM
