286 Appendix B: Specifications
01V96—Owner’s Manual
EQ Parameters
AUX1–8
Comp-type
4
On/off
Pre EQ/pre fader/post fader
Attenuator
–96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
5
On/off
On/off
—
Fader
100 mm motorized
Delay
0–29100 samples
Metering
Displayed on LCD
Peak hold on/off
INTERNAL EFFECTS
(EFFECT 1–4)
Number of
effects
4@44.1kHz, 48kHz
2@88.2kHz, 96kHz
Bypass
On/off
In/out
2-in, 2-out
Effect-in from
AUX1–8/INSERT OUT
Effect-out to
Input patch
Power Requirements
U.S./Canada
120 V, 60 Hz 90 W
Other
220–240 V, 50/60 Hz 90 W
Dimensions (H x D x W)
150 x 548 x 436 mm
Net weight
15 kg
Operating free-air temperature range
10–35°C
Storage temperature range
–20–60°C
Supplied Accessories
AC Cable
CD-ROM (Studio Manager)
Owner’s Manual
Studio Manager Installation Guide
Options
Digital interface card (MY16, MY8, MY4 series)
RACK MOUNT KIT: RK1
1. Total harmonic distortion is measured with a 6 dB/octave filter @ 80 kHz.
2. Hum & Noise are measured with a 6 dB/octave filter @ 12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave
attenuation.
3. See “Gate Parameters” on page 287.
4. See “Comp Parameters” on page 287.
5. See “EQ Parameters” on page 286.
LOW/HPF L-MID H-MID HIGH /LPF
Q
0.1–10.0
(41 points)
low shelving
HPF
0.1–10.0
(41 points)
0.1–10.0
(41 points)
high shelving
LPF
F
21.2 Hz–20.0 kHz (1/12 oct step)
G
±18 dB
(0.1 dB step)
HPF: on/off
±18 dB
(0.1 dB step)
±18 dB
(0.1 dB step)
LPF: on/off
