Yamaha MX400 - Page 16

12 Rear panel
MX400 User’s Guide
5 GROUP SUB IN jacks (+4dB)
These are unbalanced 1/4” phone jacks which input signals from sub-mixers
or other devices.
• Nominal input level: +4dB
6 2TR IN jacks (–10dBV)
These are RCA pin jacks used to input a stereo sound source.
• Nominal input level: –10dBV
7 ST SUB IN jacks (+4dB)
These are 1/4” unbalanced phone jacks which input a stereo signal from a
sub-mixer or other source.
• Nominal input level: +4dB
8 REC OUT jacks (–10dBV)
These are RCA pin jacks which output a stereo signal to a DAT or cassette
recorder. These jacks are positioned before the stereo master fader.
• Nominal output level: –10dBV
9 TAPE IN jacks (–10dBV)
These are RCA pin jacks which input a stereo source such as a DAT, stereo
cassette deck, or CD player.
• Nominal input level: –10dBV
0 ST INPUT 1/2 A jacks
These are unbalanced 1/4” phone jacks which input a stereo source. These
jacks are selected by the A/B switch.
• Nominal input level: +4dB or –10dB
A ST INPUT 1/2 B jacks
These are RCA pin jacks which input a stereo source. These jacks are selected
by the A/B switch.
• Nominal input level: +4dB or –10dB
Phantom Power Warning
To prevent hazard or damage, connect
only microphones and cables that
conform to the IEC268-15A standard.
9-E FNTM 01 3/5
0
A
B
5
6J
E
789
C
D
F
G
H
I
ON OFF
POWER
ON OFF
PHANTOM+48V
AUX SEND +4dB
GROUP INSERT I/O 0dB
GROUP OUT +4dB
ST2/MONI OUT +4dB
ST1 OUT +4dB
ST INSERT
I/O
A
A
BB
GROUP SUB IN +4dB
2TR IN ST SUB IN
TAPE INREC OUT
ST INPUT 2
ST INPUT 4
ST INPUT 1
ST INPUT 3
54321
4321
4321
RL
RL
R
L
0dB
43
21
R
L
–10dBV
R
L
–10dBV
R
L
–10dBV
R
L
+4dB
R
L
R
L
R
L/
MONO
R
L/
MONO
R
L/
MONO
R
L/
MONO
