Yamaha PSR-E223 - Panel Controls and Terminals

10 PSR-E223/YPT-220 Owner’s Manual
Setting Up
Panel Controls and Terminals
■ Front Panel
q [STANDBY/ON] switch.......................................... page 9
w [MASTER VOLUME] control .................................page 9
e [1 LISTEN & LEARN] button............................... page 29
r [2 TIMING] button ................................................page 30
t [3 WAITING] button .............................................page 31
y LESSON PART
[L] button .............................................................page 29
[R] button............................................................. page 29
u [METRONOME] button................................ pages 14, 36
i [TEMPO/TAP] button....................... pages 22, 37, 39, 40
o [SONG] button............................................. pages 16, 26
!0 [VOICE] button ............................................ pages 12, 26
!1 [STYLE] button............................................ pages 19, 26
!2 Number buttons [0]–[9], [+], [-]...........................page 26
!3 [FUNCTION] button.............................................page 43
!4 [DEMO] button..................................................... page 17
!5 [A-B REPEAT] button..........................................page 38
!6 [REW] button .......................................................page 17
!7 [FF] button ...........................................................page 17
!8 [PAUSE] button....................................................page 17
!5 [ACMP ON/OFF] button ......................................page 20
!6 [INTRO/ENDING/rit.] button................................page 23
!7 [MAIN/AUTO FILL] button...................................page 23
!8 [SYNC START] button ................................. pages 19, 40
!9 [START/STOP] button .........................................page 17
@0 [PORTABLE GRAND] button ..............................page 13
@1 [SOUND EFFECT] button ...................................page 15
@2 [REVERB] button ................................................page 32
@3 Drum Kit...............................................................page 15
■ Rear Panel
@4 MIDI IN/OUT terminals ........................................page 45
@5 SUSTAIN jack.........................................................page 9
@6 PHONES/OUTPUT jack .........................................page 9
@7 DC IN 12V jack....................................................... page 8
When the Song mode
When the Style mode
w
q
e
r
t
!5
!7
!6
!8
@3
■ Front Panel
