FRONT BRAKE
4-17
EAS22210
FRONT BRAKE
Removing the front brake pads
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
Front wheel Refer to “FRONT WHEEL” on page 4-6.
1 Brake pad retaining bolt 2
2 Brake pad 2
3 Brake pad spring 1
4 Brake pad shim 1
For installation, reverse the removal proce-
dure.
