• SET MENU TABLE / セットメニュー
AUTO SETUP
MANUAL SETUP
MAIN MENU PARAMETER
SETUP AUTO
EQ
FLAT / FRONT / [NATURAL]
START PUSH +
4
5
6
HDMI
i.LINK
OPTION
B
C
D
E
F
A
B
A
B
A
B
C
D
E
F
INPUT TRIM
AUDIO SELECT
DECODER MODE
INPUT REMANE
MULTI CH INPUT
INPUT ASSIGN
SUPPORT AUDIO
INPUT ASSIGN
AUTO PLAY
DISPLAY SET
MEMORY GUARD
SURR. INI
ZONE TEST
ZONE2 TEST
(U, C, R, T, K, A,
B, G, L models)
ZONE3 TEST
(U, C, R, T, K, A,
B, G, L models)
IN (6)
IN (7)
IN (8)
IN (9)
DVD
PHONO
TUNER
CD
MULTI CH
V-AUX
CBL/SAT
MD/TAPE
CD-R
DTV
VCR1
DVR/VCR2
DVD
PHONO
TUNER
CD
MULTI CH
V-AUX
CBL/SAT
MD/TAPE
CD-R
DTV
VCR1
DVR/VCR2
IN 1
IN 2
DIMMER
WALL PAPER
SHORT MESSAGE
VIDEO CONV.
PRESS DSP key
SPEAKER B
OUT VOL.
ZONE2 AMP.
OUT VOL.
CBL/SAT
CD
DVD
DVR/VCR2
-6.0dB ~ +6.0dB, 0.5dB step [±0.0dB]
[AUTO] / LAST
[AUTO] / LAST
Input is possible to 8 characters / 8文字まで入力可能
Input possible Character type / 入力可能文字
CAPITAL / 英大文字 A to Z
SMALL / 英小文字 a to z
FIGURE / 数字 0 to 9
Space / 空白
MARK / 記号 # * + , - . / : < > ? etc.
カタカナ ア〜ー(J model)
[6CH] / 8CH
[DVD] / DTV / CBL/SAT / VCR1 / DVR/VCR2 / V-AUX
DVD / DTV / [CBL/SAT] / VCR1 / DVR/VCR2 / V-AUX
RX-V4600 / OTHER
[<---> PLAYER] / ----> PLAYER / <---- PLAYER / --X-- PLAYER
-4 ~ 0, 1 step [0]
NONE / [YES] / GRAY BACK
OFF / [ON]
[OFF] / ON
[MAIN] / ZONE B
[VAR] / FIX
[OFF] / EXT / INT
[VAR] / FIX
MAIN MENU SUB MENU PARAMETER SETTING VALUE ([ ] INITIAL VALUE)
LARGE / [SMALL]
LARGE / [SMALL] / NONE
LARGE x1 / SMALL x1 / [SMALL x2] / LARGE x2 / NONE
YES / [NONE]
[SWFR] / FRONT / BOTH
40 / 60 / [80 (THX)] / 90 / 100 / 110 / 120 / 160 / 200 Hz
[NORMAL] / REVERSE
Meters (m) / Feet (ft)
0.30 ~ 24.00m, 0.1m step [3.00m] / 1.0 ~ 80.0ft, 0.5ft step [10.0ft]
-----ll----- -10.0 ~ +10.0dB 0.5dB step [0dB]
[OFF] / ON
Under 0.3m / [0.3-1.2m] / Over 1.2m, Under 1ft / [1-4ft] / Over 4ft
-20dB ~ ±0.0dB, 0.5dB step [±0.0dB]
[MAX] / STD / MIN
Freq 125 / [350] / 500Hz, Gain -6.0dB ~ +6.0dB, 0.5dB step [±0.0dB]
Freq 2.5k / [3.5k] / 8.0kHz, Gain -6.0dB ~ +6.0dB, 0.5dB step [±0.0dB]
[MUTE] / -20dB
0 ~ 240ms, 1ms step [0ms]
[SURROUND BACK] / PRESENCE
[MAIN] / SUB / ALL
DVD
DTV
CBL/SAT
MD/TAPE
CD-R
CD
DVD
DTV
1
2
3
BASIC
SOUND
INPUT
A
B
C
D
E
A
B
C
D
A
SPEAKER SET
SPEAKER DISTANCE
SPEAKER LEVEL
TEST TONE
THX SET
LFE LEVEL
DYNAMIC RANGE
TONE CONTROL FRQ
AUDIO OPTION
I/O ASSIGN
FRONT
CENTER
SURROUND LR
SURROUND BACK
PRESENCE
BASS OUT
Cross Over
SWFR PHASE
UNIT
FRONT L
FRONT R
CENTER
SURROUND L
SURROUND R
SURROUND BACK L
SURROUND BACK R
SWFR
PRESENCE L
PRESENCE R
FRONT L
CENTER
FRONT R
SURROUND L
SURROUND BACK L
SURROUND BACK R
SURROUND R
SWFR
PRESENCE L
PRESENCE R
SB SPEAKER DIST.
SPEAKER
HEADPHONE
SPEAKER
HEADPHONE
BASS
TREBLE
AUDIO MUTE
AUDIO DELAY
PR/SB SELECT
DUAL MONO (
J model )
C.V (A)
C.V (B)
C.V (C )
OUT (1)
OUT (2)
IN (3)
IN (4)
IN (5)
