Control of Sensor Detection and Data
Control is implemented by the sensor-sheet CPU. On some models this CPU is installed on the Hammer Sensor
sheet, while in other models it is installed on the Key Sensor sheet.
H Sensor: 1-beam 2-points
Hammer Emission Sheet
Hammer Sensor Sheet: CPU
K Sensor: 1-beam ON/OFF
Key Emission Sheet
Key Receive Sheet
K Sensor: 2-beams 4-points
Key Emission Sheet
Key Sensor Sheet: CPU
H Sensor: 1-beam 2-points
Hammer Emission Sheet
Hammer Sensor Sheet: CPU
K Sensor: 2-beams 4-points
Key Emission Sheet
Key Receive Sheet: 2 sheets
MX100II/MX100IIXG/MX1
MPX100II/MPX100IIXG/MPX1
DGPII/DGPIIXG
MP80/MP100/MP1/GT10
GPS
Sheet
Hammer Emission
CPU (Hammer Receive)
Hammer Sensor Sheet
PK-CTL
HAMMER SENSOR
Sheet
Key Emission
Key Receive Sheet
KEY SENSOR
CPU (Key Receive)
Key Sensor Sheet
MN
KEY SENSOR
Sheet
Key Emission
Sheet
Hammer Emission
CPU (Hammer Receive)
Hammer Sensor Sheet
MN
HAMMER SENSOR
Sheet
Key Emission
Key Receive
KEY SENSOR
Sheet
Key Receive
Sheet
